Controlling Windows 10 feature updates

This week is all about controlling Windows 10 feature updates. A couple of months ago a new policy type was introduced to control Windows 10 feature updates. And even more recent, support for Windows Autopilot devices was added to that policy type. That latest addition was the trigger for this blog post. In this post I’ll start with a short introduction about the different options for controlling Windows 10 feature updates, followed by more details about the Windows 10 feature updates policy. I’ll end this post by looking at the configuration options.

Introducing the control options for Windows 10 feature updates

Now let’s with an introduction about the options to control Windows 10 feature updates by using Microsoft Intune. I’m deliberately naming it controlling – and not managing – as it’s more controlling the (pace of the) installation of Windows 10 feature updates. I see managing more as being in full control of the Windows 10 (feature) updates on a device. Via Microsoft Intune it’s possible to utilize Windows Update for Business to simplify the Windows 10 update management experience in general. Utilizing Windows Update for Business is focused more on controlling the Windows 10 updates cycle, instead of approving individual updates for (specific) devices. Controlling the Windows version and controlling the installation of the quality and security updates.

It’s also good to keep in mind that Microsoft Intune only stores the policy assignments and not the updates themselves. Windows 10 devices will access Windows Update directly for the updates itself. Within Microsoft Intune the following policy types are provided to control updates:

  • Windows 10 update rings: The Windows 10 update rings policy is a collection of settings that configures setting to control when Windows 10 updates get installed. This policy type already exists for a while and enables administrators to create update rings that specify how and when Windows 10 devices should be updated with feature and quality updates. As long as the latest update is installed, the Windows 10 devices are up to date.
  • Windows 10 feature updates: (Currently public preview) The Windows 10 feature updates policy brings devices to the specified Windows version and freezes the feature set on those devices until the administrator chooses to update them to a later Windows version. While the feature version remains static, devices can continue to install quality and security updates that are available for their feature version.

As the Windows 10 feature updates policy is a new feature, the remainder of this post will focus on that feature.

Introducing the Window 10 feature updates policy

A Windows 10 feature updates policy is a pretty simplistic policy – from a configuration perspective – to control the Windows 10 feature updates on a device. When a device receives a Windows 10 feature updates policy, the device will update to the Windows version that is configured in the policy. When a device is already running a later Windows version then the Windows version that is configured in the policy, that device remains on its current Windows version. The device will not downgrade to a previous Windows version.

During the period that the Windows 10 feature updates policy is assigned to the device, the device will basically freeze on the configured Windows version (unless – as previously mentioned – the device is already running a later Windows version). That also provides the administrator more flexibility for controlling the Windows version of the device. With a Windows 10 update rings policy the administrator was limited in controlling the timeframe that a device could stay on a specific Windows version. The administrator could defer the period when the device would install a new feature update with 365 days and then pause the update assignment for another 35 days, but that was it. The Windows 10 feature updates policy actually freezes the device to the configured Windows version until the administrator modifies or removes the assigned policy.

The assigned Windows 10 feature updates policy only controls the feature updates on the device. That means that while the installed Windows version is frozen, the device can still receive and install quality and security updates for their installed Windows version. These updates will apply for the duration of support for the installed Windows version.

Limitations for the Windows 10 feature updates policy

Before looking at the current prerequisites and the configuration steps of a Windows 10 feature updates policy, it’s good to be familiar with the current limitations of this policy type.

  • When deploying a Windows 10 feature update policy to a device that also receives a Windows 10 update rings policy, the following configurations should be in place within the configured update ring:
    • The Feature update deferral period (days) setting must be set to 0.
    • The feature updates of the Windows 10 update rings policy must be running.
  • Windows 10 feature update policy cannot be applied during the Windows Autopilot process, instead the policy will apply at the first Windows Update scan after a device has finished provisioning (which is typically a day).

Also, keep in mind that this is still preview functionality. It might behave different than expected in some scenarios. At the time of writing this post I’ve seen scenarios in which this policy type might not work correctly when skipping a Windows version.

Prerequisites for the Windows 10 feature updates policy

When starting with the implementation of a Windows 10 feature updates policy, the following prerequisites must be met – at this moment – by the assigned devices to guarantee the described behavior.

  • The device must be running Windows 10 version 1703 or later
  • The device must be enrolled in Microsoft Intune and should be Azure AD joined or Azure AD registered.
  • The device must have telemetry turned on, with a minimum setting of Basic.

Configuring the Windows 10 feature updates policy

The configuration of the Windows 10 feature updates feature is actually pretty straight forward and doesn’t require a lot of configuring. The following 5 steps walk through the configuration of the Windows 10 feature updates feature and all the available configuration options.

  1. Open the Microsoft Endpoint Manager admin center portal and navigate to Devices Windows > Windows 10 feature updates to open the Windows – Windows 10 feature updates blade
  2. On the Windows – Windows 10 feature updates blade, click Create profile to open the Create feature update deployment wizard
  3. On the Deployment settings page, provide the following information and click Next
  • Name: Provide a valid name for the Windows 10 feature updates deployment
  • Description: (Optional) Provide a description for the Windows 10 feature updates deployment
  • Feature update to deploy: Select the Windows 10 version that should stick on the devices (current options are Windows 10 1803, Windows 10 1809, Windows 10 1903 and Windows 10 1909)
  1. On the Assignments page, click Select groups to include to assign the Windows 10 feature update deployment to a group of devices and click Next
  2. On the Review + create page, review the configuration of the Windows 10 feature update deployment and click Create

Administrator experience

Now let’s end this post by having a quick look at the administrator experience. Once the policy is assigned to the device, the device will check-in and install the Windows feature update according to the configured policy. The eventual result can be verified by navigating to Devices Windows > Windows 10 feature updates > [CreatedWindows10FeatureUpdatesPolicy] > End user update status. That report provides an overview of the assigned devices and their (feature) update status (as shown below).

More information

For more information about configuring updates in Microsoft Intune, refer to the documentation about Manage Windows 10 software updates in Intune.

Block Android device enrollment for specific device manufacturer

This week is all about restricting the enrollment of Android devices. More specifically, about a very recently introduced feature which is the ability to block Android device enrollment based on the manufacturer of the device. That enables the organization to prevent Android devices of specific manufacturers from enrolling in Microsoft Intune. That can be useful when the organization has a specific policy for allowed device manufacturers. In this post I’ll walk through the configuration steps, followed with the end-user experience.

Starting with this post, I’ll provide both the configuration steps via the Microsoft Endpoint Manager admin center portal and the configuration location in the Graph API (including the related JSON-snippet) as part of the configuration steps.

Configuration steps

Now let’s start by having a look at the configuration steps. These configurations can be achieved by either creating custom device type restrictions or by editting the existing default device type restriction. In the following example I’ll walk through these steps by adjusting the default device type restrictions. The following steps show how to add a device manufacturer to a list of blocked manufacturers.

  1. Open the Microsoft Endpoint Manager admin center portal and navigate to Devices > Enroll devices > Enrollment restrictions to open the Enroll devices – Enrollment restrictions blade
  2. On the Enroll devices – Enrollment restrictions blade, select the Default device type restriction and navigate to Properties to open the All Users – Properties blade
  3. On the All Users – Properties blade, navigate to the Platform settings section and click Edit to open the Platform settings page on the Edit restriction blade
  4. On the Platform settings page, provide the manufacturers to block in the Device manufacturer field (see example below) and click Review + save to continue to the Review + save page

Note: Use a comma-separated list when adding multiple manufacturers.

  1. On the Review + save page, click Save

For automation purposes, it might be better to know how to automate the device type restriction configuration. That can be achieved by using the deviceEnrollmentConfigurations object in the Graph API.

https://graph.microsoft.com/beta/deviceManagement/deviceEnrollmentConfigurations

However, keep in mind that the required properties are currently only available in the BETA version of the API. Below is an example snippet of a JSON that contains the Android Enterprise configuration with the blocked manufactures configuration, similar to the configuration via the UI.

"androidForWorkRestriction": {
    "platformBlocked": false,
    "personalDeviceEnrollmentBlocked": false,
    "osMinimumVersion": null,
    "osMaximumVersion": null,
    "blockedManufacturers": [
        "Samsung"
    ]
}

End-user experience

Now let’s end this post by having a look at the end-user experience. I’ll do that by showing the behavior on a personally-owned Android device that should enroll by using Android Enterprise work profiles to manage corporate data and apps. By default, enrollment of this type of personally-owned devices is enabled. That can be limited by using the enrollment restrictions, as shown in this post, or by simply blocking personally-owned devices.

In this scenario, I’m allowing the enrollment of personally-owned and company-owned Android devices, but I’m blocking any enrollment of Android devices from a specific device manufacturer.

When the end-user downloaded and installed the Company Portal app and started the enrollment process, at some point during the enrollment process the end-user will be blocked. While being blocked, the end-user will receive the message “Couldn’t add your device“. That message, of which an example is shown on the right, includes a clear explanation of why the device couldn’t be added. In my example the end-user is being told that the company needs the end-user to use an Android device manufacturer other then samsung.

Note: Keep in mind that the only reason that I’m using Samsung as an example in this post, is that I’ve got test Android devices of that device manufacturer. I don’t have any reasons that would actually require me to block the enrollment of Android devices from that device manufacturer.

More information

For more information about blocking Android device enrollment for specific device manufacturers, refer to the following docs:

Exclude specific groups of users or devices from an app assignment

This week another post about apps. This week it’s all about the ability to exclude a specific group of users or devices from an app assignment. That ability is not completely new, but it’s new enough to be still a little bit unfamiliar for many. It can be useful for assigning an app to a big group and still being able to exclude a small group. That can be users that should be treated a little different than the standard, like for example a test group, a demo group, or an executive group. In this post I want to have a look at those configuration options. Often I’ll also have a look at the end-user or administrative experience, but in this case there is nothing to show. It’s just an assignment configuration.

Configuration options

When working with apps the administrator has the option to assign the app to a specific group of users or devices. That can even be multiple groups. Now the administrator also has the option to exclude a specific group of users or devices. That exclusion will take precedence over an inclusion. At least for the following same group type configurations:

  • Include user groups and exclude user groups when assigning an app
  • Include device groups and exclude device group when assigning an app

An example of this would be for an administrator to assign an app to the users of the All users group and to exclude the users of the All demo users group. In that example all users except for the users of the demo users group, would get the assignment of the app. Simply because both groups are user groups. That would enable the administrator to treat the demo users differently for demo purposes.

It’s good to keep in mind that Microsoft Intune doesn’t evaluate user-to-device group relationships. When the administrator would assign apps to mixed groups, the results may not be expected. That also means that the exclusions are a service-side evaluation and not a client-side evaluation. On the service the results of the included and excluded groups are “calculated” and the result is used as the target of the assignment.

An example of this would be for an administrator to assign an app to the users of the All users group and to exclude the devices of the All demo devices group. That creates a mixed group app assignment that would result in all users (of the All users group) getting the app assignment. In other words, the exclusion does not apply. That means that it’s not recommended to mixed group app assignments.

Configuration example

Now let’s have a look at a configuration example of assigning a Win32 app in Microsoft Intune. In the following example I’ve added an assignment of the Win32 app to the users of the All users group and I want to add an exclusion for the users of the All demo users group. The following steps show how to add that exclusion by editing an existing assignment.

  1. Open the Microsoft Endpoint Manager admin center portal and navigate to Apps Windows > Windows apps to open the Windows – Windows apps blade
  2. On the Windows – Windows apps blade, select a Win32 app (or create a new one), click Properties and navigate to the Assignment section and click Edit to open the Edit application blade
  3. On the Edit application blade, on the Assignments page, click Add group, select the All demo users group and click Select
  1. By default, the newly added group will be added with the Included MODE. To adjust this, click on Included, of the newly added group entry, switch the Mode to Excluded and click OK
  1. Now the All users group should show as Included and the All demo users group should show as Excluded. Click on Review + save to navigate to the Review + save page
  1. On the Review + save page, verify the new configuration and click Save

Note: The Review + save page will, just like the Assignments section in the Properties of the app, show both groups like both groups are a required assignment.

More information

For more information about excluding specific users or groups from an app assignment, refer to the documentation about Include and exclude app assignments in Microsoft Intune and Intune Standalone – Win32 app management.

Working with (custom) detection rules for Win32 apps

After my post of last week about Working with (custom) requirements for Win32 apps only one configuration subject of Win32 apps is left that I’ve discussed in detail, the detection rules for Win32. The format of this week is similar to that post and to previous posts about the different configuration subjects of Win32 apps. Detection rules must be used to determine the presence of a Win32 app. A Win32 app can have multiple detection rules. In that case every detection rule must be met to detect the app. That will help with making sure that the app installation will only be started when the app is not yet installed. In this post I’ll start with going through the different detection rule formats and I’ll end this post by looking at the administrator experience on a Windows device.

Detection rule

Now let’s start by having a look at the available detection rules of a Win32 app in Microsoft Intune. Let’s do that by first navigating to the location in the Microsoft Endpoint Manager admin center portal that provides the different detection rule format options for Win32 apps.

  1. Open the Microsoft Endpoint Manager admin center portal and navigate to Apps Windows > Windows apps to open the Windows – Windows apps blade
  2. On the Windows – Windows apps blade, select a Win32 app (or create a new one) and click Properties > Detection rules to open the Detection rules blade

On the Detection rules blade, the different detection rule formats of Win32 apps are shown. Those detection rule formats are categorized as mentioned below.

  1. Manually configure detection rules: This detection rule format enables the administrator to use a MSI product code, file or folder information or registry information for detecting the app.
  2. Use custom detection rules: This detection rule format enables the administrator to use a custom script for detecting the app.

The first category contains manual configurable detection rules. The manual configurable detection rules contains three different rule types that can be used to indicate the presence op the app. The first rule type in that list is MSI. That rule type enables the administrator to create a detection rule that must detect a specific MSI, or even a specific MSI version. This detection rule type can only be used once. A detection rule of this type requires the following configuration properties.

  • MSI product code – This property enables the administrator to configure the specific MSI product code that should be used to detect the installation of the app. When the installation contains an MSI, and this rule type is used, this property will be automatically populated.
  • MSI product version check – This property enables the administrator to configure also a specific version of the MSI product code that should be used to detect the installation of the app.

The second rule type in that list is File. That rule type enables the administrator to create a detection rule that must detect a specific file or folder, date, version, or size to determine the installation of the Win32 app. A detection rule of this type requires the configuration properties as mentioned below. This rule type is with its configuration properties nearly equal to the File rule type within requirement rules.

  • Path – This property enables the administrator to configure the full path of the folder that contains the file or folder that should be used to detect the installation of the app.
  • File or folder – This property enables the administrator to configure the file or folder that should be used to detect the installation of the app.
  • Detection method – This property enables the administrator to configure the method that should be used to detect the installation of the app. The following self explaining options are available.
    • File or folder exists
    • Date modified
    • Date created
    • String (version)
    • Size in MB
  • Associated with a 32-bit app on 64-bit clients – This property enables the administrator to configure that path environment variables are in 32-bit (yes) or 64-bit (no) context on 64-bit clients.

The third rule type in that list is Registry. That rule type enables the administrator to create a detection rule that must detect a specific registry setting based on value, string, integer, or version to determine the installation of the Win32 app. A detection rule of this type requires the configuration properties as mentioned below. This rule type is with its configuration properties nearly equal to the Registry rule type within requirement rules.

  • Key path – This property enables the administrator to configure the full path of the registry entry containing the value that should be used to detect the installation of the app.
  • Value name – This property enables the administrator to configure the name of the registry value that should be used to detect the installation of the app. When this property is empty, the detection will happen on the default value. The default value will also be used as detection value if the detection method is other than file or folder existence.
  • Detection method – This property enables the administrator to configure the method that should be used to detect the installation of the app. The following self explaining options are available.
    • Key exists
    • Key does not exist
    • String comparison
    • Version comparison
    • integer comparison
  • Associated with a 32-bit app on 64-bit clients – This property enables the administrator to configure that the search is in the 32-bit registry (yes) or in the 64-bit registry (no) on 64-bit clients

The second category contains custom scriptable detection rules. That is the most advanced rule format. That rule format enables the administrator to create detection rules that can check on basically anything that can be scripted, as long as the script has the correct output. A detection rule of that type requires the configuration properties as mentioned below. This rule type has some similarities with the Script rule type within the requirement rules. The main difference is with the output of this rule type as it’s more limited. In this rule type the detection of the Win32 app is based on the execution success of the script in combination with any output. It doesn’t matter what the output is.

  • Script name – This property enables the administrator to provide a name for the script.
  • Script file – This property enables the administrator to select a script that will be used to detect the installation of the app. When the script exit code is 0 and STDOUT contains any data, the app is detected (see table below for a summary).
  • Run script as 32-bit process on 64-bit clients – This property enables the administrator to configure the script to run in a 32-bit process (yes) or in a 64-bit process (no) on 64-bit clients.
  • Enforce script signature check – This property enables the administrator to configure that the script signature should be verified (yes) or that the signature verification should be skipped (no).
Exit codeData read from STDOUTDetection state
0EmptyNot detected
0Not emptyDetected
Not zeroEmptyNot detected
Not zeroNot EmptyNot detected

Administrator experience

Let’s end this post by having a look at the behavior of custom script detection rules on a Windows 10 device. The most advanced option. To do that I’ve used a really simple script that will detect the installation of Foxit Reader by looking at a specific directory. That can also be achieved by using a File rule type, but it’s an easy example for showing the functionality of custom script rule types. When the specific path is found, the script will output “Found it!“. That means that the detection rule will provide an output, when the detection was successful.

if (Test-Path "$($env:ProgramFiles)\Foxit Software\Foxit Reader\FoxitReader.exe") {
    Write-Host "Found it!"
}

When adding this script as a detection rule to a Win32 app and deploying that app as a required app to a user or a device, the installation process can be followed very good in the IntuneManagedExtension.log. That includes the process of detecting the installation of the app by going through the detection rule(s). Below is that example. It walks through the process of checking the detection rule(s) of the Win32 app. It shows the start of the script, the result of the script and following the detection state of the Win32 app (based on the result of the detection rule).

More information

For more information about the Win32 app functionality in Microsoft Intune, refer to the documentation about Intune Standalone – Win32 app management.

Working with (custom) requirements for Win32 apps

A few months ago I did a post about Working with the restart behavior of Win32 apps and a few months before that I did a post about Working with Win32 app dependencies. This week is similar to those post. This week is also about Win32 apps, but this week it’s about working with requirements for Win32 apps. Requirements can be used to make sure that the Win32 app will only install on a device that meets specific requirements. That means that requirements for Win32 apps, bring a lot of options and capabilities, which enable a lot of scenarios. Think about deploying a Win32 app to a user group and only installing on a specific device brand, type, or model. That can be achieved by using requirements. In this post I’ll quickly go through the different standard available requirement types, followed by a more detailed look at the custom script requirement type. I’ll end this post by looking at the administrator experience on a Windows device.

Requirement type

Now let’s start by having a look at the standard available requirement types within Microsoft Intune. Let’s do that by first navigating to the location in the Microsoft Endpoint Manager admin center portal that provides the different requirement options for Win32 apps.

  1. Open the Microsoft Endpoint Manager admin center portal and navigate to Apps Windows > Windows apps to open the Windows – Windows apps blade
  2. On the Windows – Windows apps blade, select a Win32 app (or create a new one) and click Properties > Requirements to open the Requirements blade

On the Requirements blade, the different standard available Win32 app requirement types are shown. Those requirement types are shown and explained below.

  1. Operating system architecture: This requirement enables the administrator to select the required architecture (32-bit | 64-bit) of the operating system that is needed for the Win32 app. This is a required configuration.
  2. Minimum operating system: This requirement enables the administrator to select the minimum operating system version that is needed to install the Win32 app. This is a required configuration.
  3. Disk space required (MB): This requirement enables the administrator to configure the free disk space that is needed on the system drive to install the Win32 app. This is an optional requirement.
  4. Physical memory required (MB): This requirement enables the administrator to configure the physical memory (RAM) that is required to install the Win32 app. This is an optional requirement.
  5. Minimum number of logical processors required: This requirement enables the administrator to configure the minimum number of logical processors that are required to install the Win32 app. This is an optional requirement.
  6. Minimum CPU speed required (MHz): This requirement enables the administrator to configure the minimum CPU speed that is required to install the Win32 app. This is an optional requirement.
  7. Configure additional requirement rules: See below.

The six requirements mentioned above are the standard available and easy to configure Win32 app requirement types. Besides those requirements, it’s also possible to add more advanced requirement types (as shown with number 7 above). The first requirement in that list of more advanced requirement types is File. That requirement type enables the administrator to create requirement rule that must detect a file or folder, date, version, or size. A requirement rule of that type requires the following configuration properties.

  • Path – This property enables the administrator to configure the full path of the folder that contains the file or folder that should be detected.
  • File or folder – This property enables the administrator to configure the file or folder that should be detected.
  • Property – This property enables the administrator to configure the type of rule that should be used to validate the presence of the Win32 app. The following self explaining options are available.
    • File or folder exists
    • File or folder does not exist
    • Date modified
    • Date created
    • String (version)
    • Size in MB
  • Associated with a 32-bit app on 64-bit clients – This property enables the administrator to configure that path environment variables are in 32-bit (yes) or 64-bit (no) context on 64-bit clients.

The second requirement in that list of more advanced requirement types is Registry. That requirement type enables the administrator to create requirement rule that must detect a registry setting based on value, string, integer, or version. A requirement rule of that type requires the following configuration properties.

  • Key path – This property enables the administrator to configure the full path of the registry entry containing the value that should be detected.
  • Value name – This property enables the administrator to configure the name of the registry value that should be detected. When this property is empty, the detection will happen on the default value. The default value will also be used as detection value if the detection method is other than file or folder existence.
  • Registry key requirement – This property enables the administrator to configure the type of registry key comparison that should be used to determine how the requirement rule is validated. The following self explaining options are available.
    • Key exists
    • Key does not exist
    • String comparison
    • Version comparison
    • integer comparison
  • Associated with a 32-bit app on 64-bit clients –This property enables the administrator to configure that the search is in the 32-bit registry (yes) or in the 64-bit registry (no) on 64-bit clients.

The third requirement in that list of more advanced requirement types is Script. That is the most advanced requirement type. That requirement type enables the administrator to create requirement rules that can check on basically anything that can be scripted, as long as the script has the correct output. A requirement rule of that type requires the following configuration properties.

  • Script name – This property enables the administrator to provide a name for the script.
  • Script file – This property enables the administrator to select a script that will be used to verify custom requirements. When the script exit code is 0, Intune will detect the STDOUT in more detail.
  • Run script as 32-bit process on 64-bit clients – This property enables the administrator to configure the script to run in a 32-bit process (yes) or in a 64-bit process (no) on 64-bit clients.
  • Run this script using the logged on credentials – This property enables the administrator to configure the script to run using the credentials of the signed in user (yes) or using the SYSTEM context (no).
  • Enforce script signature check – This property enables the administrator to configure that the script signature should be verified (yes) or that the signature verification should be skipped (no).
  • Select output data type – This property enables the administrator to configure the data type that is used to determine a requirement rule match. The following self explaining options are available.
    • String
    • Date and Time
    • Integer
    • Floating Point
    • Version
    • Boolean

This advanced requirement type enables an administrator to check on basically anything. Based on the information provided above, the script should run successful (exit code 0) and provide an output in the selected data type (string, date and time, integer, floating point, version or boolean).

Administrator experience

Let’s end this post by having a look at the behavior of requirement rules a on a Windows 10 device. To do that I’ve used a really simple script that will check the manufacturer of the device. When the manufacturer matches the specified manufacturer, the script will output “Found it!“. That means that the requirement rule should look for output data of the type String. And more specifically a String that equals “Found it!“.

if ((Get-WmiObject Win32_ComputerSystem).Manufacturer -eq "Microsoft Corporation") {
    Write-Output "Found it!"
}

When adding this script as a requirement rule to a Win32 app and deploying that app as a required app to a user or a device, the installation process can be followed very good in the IntuneManagedExtension.log. That includes the process of verifying the requirement rules that should be checked. Below is that example. It walks through the process of checking the requirement rules for the Win32 app. It shows the start of the script, the result of the script and following the applicability of the Win32 app (based on the result of the requirement rule).

More information

For more information about the Win32 app functionality in Microsoft Intune, refer to the documentation about Intune Standalone – Win32 app management.

Device compliance based on custom configuration baselines

This week is all about the new feature to include a custom configuration baselines as part of a compliance policy assessment. That’s a new feature that is introduced in Configuration Manager, version 1910. That will also make this a followup on the post I did earlier this year about using the power of ConfigMgr together with Microsoft Intune to determine device compliance. This will be added functionality, as it’s now possible to make custom configuration baselines part of the device compliancy check. For both, Configuration Manager managed devices and co-managed devices. Even when the workload is switched to Microsoft Intune.

Introduction

This option that makes it possible to use a custom device configuration baseline part of a compliancy policy, opens up a whole new world of possibilities. Especially when knowing that this can also be used when co-managing devices. This enables organisations to create a custom device configuration baseline for specific business requirements that cannot be captured by using the default functionalities that are available for Configuration Manager and Microsoft Intune.

This provides a lot of flexibility for devices that are either managed by Configuration Manager, or that are co-managed by using a combination Configuration Manager and Microsoft Intune. In the latter scenario, that even still provides that flexibility when the compliance policies workload is switched to Microsoft Intune. In that case Microsoft Intune can be configured to take the ConfigMgr compliance assessment result as part of the overall compliance status. The info gets sent to Azure AD and can be used for conditional access. In this post I’ll show how to correctly configure the device compliance policy, the configuration baseline and (optionally) the Configuration Manager compliance.

Before starting with the different configurations it’s good to keep in mind that if the compliance policy evaluates a new baseline that has never been evaluated on the client before, it may report non-compliance at first. This occurs if the baseline evaluation is still running when the compliance is evaluated.

Configure device compliance policy

The first configuration that should be in place is the device compliance policy. The device compliance policy is used to determine the compliance status of the device. Within the device compliance policy, a new rule is available that will enable the evaluation of configuration baselines as part of the compliance of the device. The following steps walk through the creation of a new device compliance policy including the required rule. The device compliance policy can be deployed like any other device compliance policy.

  1. Open the Configuration Manager administration console and navigate to Assets and Compliance > Overview > Compliance Settings > Compliance Policies
  2. Click Create Compliance Policy to open the Create Compliance Policy Wizard
  3. On the General page, provide the following information and click Next
  • Name: Provide a valid name for the compliance baseline
  • Description: (Optional) Provide a description for the compliance baseline
  • Select Compliance rules for devices managed with Configuration Manager client
  1. On the Supported Platforms page, select Windows 10 and click Next
  1. On the Rules page, perform the following actions and click Next
  • Click New to open the Add Rule dialog box
  • On the Add Rule dialog box, select Include configured baselines in compliance policy assessment and click OK
  1. On the Summary page, click Next
  2. On the Completion page, click Close

Configure configuration baseline policy

The second configuration that should be in place is the configuration baseline policy. The configuration baseline policy is used to configure, or verify, specific configuration on a device. Within a configuration a new settings is available that will make the evaluation of the configuration baseline a part of the compliance evaluation. The following steps will walk through the process of creating a new configuration baseline including the new setting. In my example I’m adding a configuration item that will verify if the local administrators comply the the organisation defaults. The configuration baseline can be deployed like any other configuration baseline.

  1. Open the Configuration Manager administration console and navigate to Assets and Compliance > Overview > Compliance Settings > Configuration Baselines
  2. Click Create Configuration Baseline to open the Create Configuration Baseline dialog box
  1. On the Create Configuration Baseline dialog box, provide the following and click OK
  • Name: Provide a valid name for the configuration baseline
  • Description: (Optional) Provide a description for the configuration baseline
  • Configuration data: Select the required configuration items that should be part of this configuration baseline
  • Select Always apply the baseline even for co-managed devices
  • Select Evaluate the baseline as part of compliance policy assessment

The combination of these settings will make sure that the configuration baseline is applied to co-managed devices and that the configuration baseline will be evaluated as part of the compliance. Keep in mind that any baseline with the second option selected, that is deployed to the user, or to the user’s device, is evaluated for compliance.

(Optional) Configure Configuration Manager Compliance

An optional configuration is to configure Microsoft Intune to also look at information of Configuration Manager for determining the compliance. In my scenario that is a required configuration as I’m using it in combination with co-managed devices. Within a compliance policy a setting is available that will require compliance from Configuration Manager. The following steps walk through the configuration of that setting in a device compliance policy. Nothing more, nothing less. The device compliance policy can be assigned like any other device compliance policy.

  1. Open the Microsoft 365 Device Management portal and navigate to Devices Windows > Compliance policies to open the Windows – Compliance policies blade
  2. On the Windows – Compliance policies blade, click Create Policy to open the Create Policy blade
  3. On the Create Policy blade, provide the following information and click Create
  • Name: Provide a valid name for the compliance policy
  • Description: (Optional) Provide a description for the compliance policy
  • Platform: Select Windows 10 and later
  • Settings: See step 4 and 5
  • Actions for noncompliance: Leave default (for this post)
  • Scope (Tags): Leave default (for this post)
  1. On the Windows 10 compliance policy blade, select Configuration Manager Compliance to open the Configuration Manager Compliance blade
  2. On the Configuration Manager Compliance blade, select Require with Require device compliance from System Center Configuration Manager and click OK to return to the Windows 10 compliance policy blade and click OK

Experience

Now let’s end this post by having a look at the end-user experience. In my scenario I’ve created a custom configuration baseline that will verify the number of local administrators on the device. When it’s above a specific number of local administrators, the device is considered not compliant as the device might be compromised. In that case the end-user will receive a message in the Company Portal app as shown below. It explains the end-user that the security settings should be updated and to look for more information in Software Center.

When looking at Software Center it actually provides exactly the same message to the end-user. It provides the end-user with the message that the security settings should be updated. For more information the end-user should contact the support department. So make sure that the requirements are clear to the end-user.

More information

For more information see the Include custom configuration baselines as part of compliance policy assessment section of the Create configuration baselines doc.

The different ways of (re)naming Windows 10 devices

This week is all about Windows 10 devices. More specifically about (re)naming Windows 10 devices. And all that by using standard available functionality without custom scripting. This post will bring different posts together that I did over the last couple of years and will introduce one new configuration option that was recently introduced within Windows Autopilot. In this post I’ll go through the different (configuration) options for (re)naming Windows 10 devices.

Configuration options

Now let’s dive into the different configuration options. All of these configuration options are from a MDM-Intune-Autopilot perspective. Scripting a device rename action could also be scripted by using PowerShell, but for this post I want to rely on built-in functionality.

Custom device configuration profile

The first configuration option that I want to mention is the configuration that is available on every Windows 10 device, as it relies on Windows 10 MDM. This configuration relies on a custom device configuration profile, as shortly explained below. The actual behavior is similar to what will happen when selecting a device and clicking Restart.

When creating a custom device configuration profile, provide at least the following information on the Custom OMA-URI Settings blade.

  • Name: Provide a valid name;
  • Description: (Optional) Provide a description
  • OMA-URI: ./Device/Vendor/MSFT/Accounts/Domain/ComputerName
  • Data type: Select String
  • Value: CLDCLN%SERIAL% (or use the other example of CLDCLN%RAND:6%)

For more information about the custom device configuration option, please have a look at my blog post specifically about this subject.

Domain join device configuration profile

The second configuration option that I want to mention is the configuration that is only available for Windows Autopilot deployments that require a hybrid Azure AD join. In that case a domain join device configuration profile should be used to configure the name of the Windows 10 device. Below is a short explanation.

When creating a custom device configuration profile, provide at least the following information on the Domain Join (Preview) blade.
  • Computer name prefix: Provide a computer name prefix. The remaining characters of the 15 characters of a computer name will be random
  • Domain name: Provide the domain name that the device will join
  • Organizational unit: (Optional) Provide the OU that the computer account is created in

For more information about the domain join device configuration option, please have a look at my blog post specifically about this subject.

Windows Autopilot deployment profile

The third configuration option that I want to mention is the configuration that is only available for Windows Autopilot deployments that require Azure AD join. In that case the Windows Autopilot deployment profile should be used to configure the name of the Windows 10 device. Below is a short explanation.

When creating a Windows Autopilot deployment, provide at least the following information on the Create profile blade, on the Out-of-box experience (OOBE) section.

  • Deployment mode: Select User-Driven, or Self-Deploying, as both option can be used in combination with applying a computer name template
  • Join to Azure AD as: Select Azure AD joined to join the device to Azure AD during the Windows Autopilot user-driven experience
  • (When applicable) End user license agreement (EULA): Select Hide to hide the EULA during the Windows Autopilot user-driven experience
  • (When applicable) Privacy Settings: Select Hide to the hide the privacy settings during the Windows Autopilot user-driven experience
  • (When applicable) Hide change account options: Select Hide to hide the change account options during the Windows Autopilot user-driven experience
  • User account type: Select Administrator to only make any user on the device an administrative user
  • (When applicable) Language (Region): Select the applicable language and configure the keyboard
  • (When applicable) Allow White Glove OOBE: Select Yes, when using in combination with White Glove
  • Apply computer name template: Create a computer name, according to the configured template, for devices at initial startup

For more information about the Windows Autopilot deployment profile option, please have a look at my blog post specifically about this subject. This is just one example about Windows Autopilot on my blog that contains this configuration option.

Windows Autopilot device property

The fourth configuration option that I want to mention is the configuration that is only available for Windows Autopilot deployments that require Azure AD join. In this case it’s a property of the Windows Autopilot device that can be used for configuring the configuring the device. The device name will only be configured during the Windows Autopilot deployment. Below are the steps for configuring the device name for Windows Autopilot devices.

After adding a device to Windows Autopilot the following steps help with adjusting the device name.

  • Open the Microsoft 365 Device Management portal and navigate to Devices Windows > Windows enrollment > Devices to open the Windows Autopilot devices blade
  • On the Windows Autopilot devices blade, select the applicable device to open the Properties blade
  • On the Properties blade, provide a custom name with Device Name and click Save.

This can also be automated via the WindowsAutopilotIntune module.

Note: It’s possible to configure the device name for all devices, but are ignored with Hybrid Azure AD joined deployment.

More information

For more information about the different device (re)name options, please refer to the following articles:

Report-only mode for conditional access

This week is, like last week, about a awareness for new feature that is introduced with conditional access. Last week was all about the recently introduced Conditional Access Insights workbook. In that post I already mentioned the Report-only mode for conditional access policies. In this post I want to focus on that Report-only mode. Report-only mode is a new state of a conditional access policy state that allows IT administrators to evaluate the impact of conditional access policies before enabling them in their environment. That enables the IT administrators to anticipate on the number and names of users impacted by common deployment initiatives such as blocking legacy authentication, requiring multi-factor authentication, or implementing sign-in risk policies. A great step forward.

In this post I’ll walk through the steps of configuring Report-only mode for conditional access policies, followed by looking at the end-user experience. I’ll end this post by looking at the administrator experience.

Configure report-only mode

Let’s start by having a look at the steps to configure the Report-only mode for a conditional access policy. These steps will walk through the creation of a new conditional access policy, with a focus on configuring the Report-only mode. The exact configuration of the conditional access policy assignments and conditions are not part of that focus. The following three steps walk through that configuration.

  1. Open the Azure portal and navigate to Azure Active Directory  > Security > Conditional access (or open the Microsoft 365 Device Management portal and navigate to Endpoint security Conditional access) to open the Conditional access – Policies blade
  2. On the Conditional access – Policies blade, click New policy to open the New blade
  3. On the New blade, configure the assignment and conditions to filter the users and cloud apps that should be targeted by the conditional access policy. After configuring the conditions it’s time to look at the access controls. The access controls are the configuration that eventually might impact the end-user. In the access controls, the grant control determines that behavior. In the grant control the IT administrator can configure the requirements that should be met for accessing the cloud app for the end-user. Depending on the configured requirements, there might be a minimal impact for the end-user (see Figure 1 and and Figure 2 about the messages that are shown about the impact of the conditional access policy based on the configured requirements). After configuring the grant control, select Report-only with Enable policy (also shown in Figure 1) and click Create.

End-user experience

Depending on the configuration that is used in the grant control, of the conditional access policy, the end-user might have a slight impact when using the Report-only mode. The table below is a summary of the available requirements in combination with the potential impact. This table is based on the information as shown during the configuration of the conditional access (see Figure 2), as I haven’t been able to get the mentioned experience on my test devices. I’ve tested with a Samsung Galaxy 10, iPad 2018 and iPhone X.

RequirementPotential user impact
Require multi-factor authentication No impact
Require device to be marked as compliantMay prompt users on macOS, iOS and Android devices to select a device certificate
Require Hybrid Azure AD joined device No impact
Require approved client appMay prompt users on macOS, iOS and Android devices to select a device certificate
Require app protection policyMay prompt users on macOS, iOS and Android devices to select a device certificate

Administrator experience

An interesting part to look at is the experience of the IT administrator. That can be achieved by looking at the Conditional Access Insights workbook (as shown last week). The Conditional Access Insights workbook can be used to get the insights of the different Report-only mode conditional access policies. The data in the workbook can be filtered to only show information about Report-only mode conditional access policies, or even only data of a specific conditional access policy.

Besides that workbook, the Sign-ins monitoring of Azure AD also provides a new tab in the details of a sign-in. That tab is the Report-only (Preview) tab. As shown below that tab provides information about the different Report-only mode conditional access policies that were applicable to the sign-in. Per conditional access policy, the result is shown of the sign-in. That result will show what the effect would be of that conditional access policy and that information will help with determining the impact of enabling that conditional access policy.

Below is an overview of the different result states of a Report-only conditional access policy. Almost all of these results are shown in Figure 3 above (with the exception of the user action required result).

ResultExplanation
Report only: FailureThe configured conditional access policy conditions were satisfied, but not all the required (non-interactive) controls were satisfied.
Report only: SuccessThe configured conditional access policy conditions and required (non-interactive) controls were satisfied.
Report only: Not appliedNot all configured conditional access policy conditions were satisfied.
Report only: User action requiredThe configured conditional policy conditions were satisfied, but a user action would be required to satisfy the required controls.

More information

For more information regarding report-only, please refer to the following documents:

Conditional Access Insights

This week is all about creating awareness for the Conditional Access Insights workbook. This workbook is currently still in preview and is using Azure Monitor workbook functionality. The Conditional Access Insights workbook contains sign-in log queries that can help IT administrators with getting insights on the impact of conditional access policies. That is useful for troubleshooting, for following trends and for testing the latest introduction to conditional access of Report-only policies. Especially the latest category can be easily verified by using the Conditional Access Insights workbook. In this post I’ll walk trough the steps of creating a Log Analytics workspace (to store Azure Monitor log data), followed by the steps to send Azure AD sign-in information to Azure Monitor logs.I’ll end this post by actually looking at the Conditional Access Insights workbook.

Create a Log Analytics workspace

The first step to prepare for using the Conditional Access Insights workbook, is to create a Log Analytics workspace. A Log Analytics workspace is a unique environment for Azure Monitor log data. Each Log Analytics workspace has its own data repository and configuration, and data sources and solutions are configured to store their data in a particular workspace. To create a Log Analytics workspace simply follow the 2 steps below.

  1. Open the Azure portal and navigate to  All services  > Log Analytics workspaces to open the Log Analytics workspaces blade
  2. On the Log Analytics workspaces blade, provide the following information and click OK
  • Select Create New
  • Log Analytics Workspace: Provide a unique name for the Log Analytics workspace
  • Subscription: Select a valid subscription for the Log Analytics workspace
  • Resources group: Select an existing resource group for the Log Analytics workspace, or click Create new to create a new resource group for the Log Analytics workspace
  • Location: Select a location for the Log Analytics workspace
  • Pricing tier: Select a pricing tier for the Log Analytics workspace

Note: Alternatively the Log Analytics workspace can be created during the process of configuring the diagnostic settings of Azure AD.

Send logs to Azure Monitor logs

The second step to prepare for using the Conditional Access Insights workbook, is to send the Azure AD sign-in logs to Azure Monitor logs (previously known as Log Analytics). Azure Monitor logs allows the administrator to query data to find particular events, analyze trends, and perform correlation across various data sources. To send the Azure AD sign-in logs to Azure Monitor logs simply follow the 3 steps below.

  1. Open the Azure portal and navigate to  Azure Active Directory  > Diagnostic settings to open the [Azure AD] > Diagnostic settings blade
  2. On the [Azure AD] > Diagnostic settings blade, click Add diagnostic settings to open the Diagnostic settings blade
  3. On the Diagnostic settings blade, provide the following information and click Save
  • Name: Provide a unique name for the diagnostic settings configuration
  • Select Send to Log Analytics
  • Subscription: Select a valid subscription for the Azure Monitor logs
  • Log Analytics Workspace: Select the previously created Log Analytics workspace as a location to store the Azure Monitor logs
  • Log: Select SignInLog

Conditional Access Insights workbook

After making sure that the Azure AD sign-in information is send to Azure Monitor logs, the Conditional Access Insights workbook can be used to get insights in the log data. This workbook contains sign-in log queries that can help IT administrators monitor the impact of conditional access policies. This provides the IT administrators with the ability to report on how many users would have been granted or denied access. This workbook contains details per condition so that the impact of a policy can be contextualized per condition. The following steps walk through navigating to and through the Conditional Access Insights workbook.

  1. Open the Azure portal and navigate to  Azure Active Directory  > Workbooks to open the [Azure AD] > Workbooks blade

Tip: Also make sure to take a look at the other available workbooks, as those workbooks provide a lot of insights about the different sign-ins. Really useful for insights.

  1. On the [Azure AD] > Workbooks blade, click Conditional Access Insights (Preview) to open the Conditional Access Insights (Preview) workbook

The Conditional Access Insights workbook provides the IT administrator with a lot of insights based on the Azure AD sign-in information. The figures above show the following information:

  • Figure 4 shows the parameter selection and the Impact summary section of the workbook. The parameter selection section provides five parameters to filter the insights of the workbook: Conditional Access Policy, Time Range, User, Apps and Data View. The first filter can also be used to easily verify the impact of the recently Report-only conditional access policies, as the insights can be filtered to a specific conditional access policy. The Impact summary section, shows a quick overview of the results for the selected conditional access policy in the specified time range. Clicking on the different tiles will further filter the breakdown sections.
  • Figure 5 and 6 show the Breakdown per condition and sign-in status section of the workbook. The Breakdown per condition and sign-in status section shows the impact of the selected conditional access policies broken down by each of six conditions: Device state, Device platform, Client apps, Sign-in risk, Location and Applications. Clicking on the logs sign with a breakdown, will open the used query in the logs viewer. That will provide the kql-query that is used to filter the right information.
  • Figure 7 shows the Sign-in details section of the workbook. The Sign-in details section enables the IT administrator to investigate individual sign-ins, filtered by the parameters selected in the workbook. Search for individual users, sorted by sign-in frequency, and view their corresponding sign-in events.

More information

For more information regarding conditional access insights, refer to the following documents:

Working with the restart behavior of Win32 apps

A long time ago, I did a post about Working with the restart behavior of Applications in ConfigMgr 2012. That post is still being read pretty well. Based on the interest of that post, and the introduction of nice new features to the Win32 apps, I thought it would be a good idea to redo that post for Microsoft Intune. Before an IT administrator had to be creative to work with, or work around, the restart behavior of Win32 apps. Either by wrapping installations and capturing the exit code, or by tuning the translation of an return code. With the latest adjustments to the Win32 apps, within Microsoft Intune, the IT administrator has more options to actually work with the return code of an Win32 app installation. These configuration options are similar to the configuration options within the app model of ConfigMgr. In this post I’ll discuss the 2 layers that together define the restart behavior after the installation of Win32 apps.

Return codes

When looking at the restart behavior after the installation of Win32 apps, the first thing that should be looked at is the return code after the installation. By default, when adding a Win32 app to Microsoft Intune, a list of standard return codes is added to indicate post-installation behavior (see figure below). These are often used return codes. When the Win32 app installation ends with a different return code, additional entries can be added. This configuration is available via [Win32 app] > Properties > Return codes.

Fore every return code a code type can be configured. The code configures the post-installation behavior of the Win32 app. The following code types are available and can be configured with the return code to apply the mentioned behavior:

  • Failed – The Failed return code indicates that the Win32 app installation failed.
  • Hard reboot – The Hard reboot return code indicates that the device is required to restart to complete the installation. Additional Win32 apps cannot be installed on the device without restart. The user will be notified about the required restart.
  • Soft reboot – The Soft reboot return code indicates that the next Win32 app is allowed to be installed without requiring a restart, but a restart is necessary to complete the installation of the installed Win32 app. The user will be notified about the restart.
  • Retry – The Retry return code indicates that the Win32 app installation is retried three times. The installation will wait for 5 minutes between each attempt.
  • Success – The Success return code indicates the Win32 app installation was successful.

Enforce device restart behavior

The second thing that should be looked at is how the device will react on the configured return code. By default, when adding a Win32 app to Microsoft Intune, the default device restart behavior is set to App install may force a device restart (see figure below). This configuration will make sure that the device will restart after the Win32 app installation, if needed, but still in an acceptable manner. The restart behavior can be configured to respond to return code differently. That configuration is available via [Win32 app] > Properties > Program.

Multiple device restart behavior configurations are available. And all these configuration options have their own effect on the return code of the Win32 app installation. The following device restart behaviors are available and can be configured to apply the mentioned behavior (including a short explanation about the expected behavior):

  • Determine behavior based on return codes: This option means that the device will restart based on the configured return code. With this configuration a Hard reboot return code will immediately trigger a restart of the device and a Soft reboot return code will notify the user that a restart is required to finish the installation.
  • No specific action: This option means that the installation will suppress device restarts during the Win32 app installation of MSI-based apps. Effectively that means that parameters are added to the installation command line of MSI-based apps to suppress device restart. With this configuration a Hard reboot return code will notify the user that a restart of the device will be triggered in 120 minutes and a Soft reboot return code will notify the user that a restart is required to finish the installation.
  • App install may force a device restart: This option means that the Win32 app installation is allowed to complete without suppressing restarts. With this configuration a Hard reboot return code will notify the user that a restart of the device will be triggered in 120 minutes and a Soft reboot return code will notify the user that a restart is required to finish the installation.
  • Intune will force a mandatory device restart: This option means that a successful Win32 app installation will always restart the device. With this configuration any successful return code will immediately trigger a restart of the device.

More information

For more information about the Win32 app functionality in Microsoft Intune, refer to the documentation about Intune Standalone – Win32 app management.
